Patented Digital Motion Detection
Patented Auto Pulse Signal Processing
Digital Shield algorithm software with adjustable sensitivity
Single or Dual Edge Processing
Automatic Temperature Compensation
Solid-state relay

Two dual element sensors (determine if movement is incoming or outgoing)
Ideal for protecting open balconies and patio doors
One incoming detection relay output
One outgoing detection relay output
Adjustable return delay timer (exit and re-enter without causing an alarm)
67cm x 4.8m (2.2ft x 16ft) and 60cm x 4.8m (2ft x 16ft)
See Features and Specifi cations Common to All Digital Motion Detectors on page 2, except dual edge processing and metal shield
Specifi cations: 15mA maximum current consumption;
2m to 4m (7ft to 14ft) installation height;
two alarm outputs (form A relay 100mA/28Vdc, N.C.)
