Fussy Logical Intelligent Analysis,low rate of false alarm
360°all-dimensional detecting and 3 infrared lenses
Sensitivity level: High, Medium and low for your selection
Anti-jamming Mode: 1(week)/2(strong) modes available for your selection.
Built-in anti-tamper
Automatic temperature compensation to ensure the detecting sensitivity
EMI and white- light immunity to reduce the false alarm
SMT adopted and high anti-jamming
Working Voltage:DC 9-15V
Static Current:≤25 mA (12V DC)
Working Current:≤20mA (12V DC)
Installment Height:2.5m～3.5m
Detecting Angle:360°
Detecting Coverage: diameter:8-15m
Open Circuit Alarm Output:100mA /24V
Working Environment: temperature:－10℃—40℃; relative humidity:≤80%
Dimension:Ф158*77mm
