Hard spherical interchangeable lenses with LP filter for best immunity against visible light
Optional black lenses with LP filter for industrial applications
Diffractive reflection mirror for creep zones
VLSI based electronics with movement speed spectrum analysis
Unique quad element pyro sensor
Bi-directional temperature compensation
Height installation calibration free from 1.5m to 3.6m

TECHNICAL SPECIFICATIONS
Power Input: 7.8 - 16 Vdc
Current Draw Active / Standby: 9 mA
Detection Method: Quad element PIR
Sensitivity: Δ2°C (Δ3.6°F) at 0.6 m/sec (2 ft/sec)
Detection Speed: 0.5 - 1.5 m/sec (1.5 - 5 ft/sec)
Bi Directional Temperature: YES
Pulse Count: 1,2-automatic switch from 2 to 3 depending on speed spectrum analysis
Alarm Period: 1.6 sec
Alarm Output: N.C 28VDC 0.1 A with 10 Ohm series protection resistor
Tamper Switch: N.C 28VDC 0.1A with 10 Ohm series protection resistor - open when cover is removed
Warm Up Period: 30 sec
LED Indicator: Led is ON during alarm
Operating Temperature: -20°C to +50°C (-4°F to +122°F)
RFI Protection: ≥ 30V/m 10 - 1000MHz
EMI Protection: 50,000V of electrical interference from lightning or power through
Visible Light Protection: stable against halogen light 2.4m(8ft) or reflected light
Dimensions: 106mm x 68.5mm x 57mm (4.2”x2.7”x2.3”)
Weight: 90 gr. ( 3.2 oz )
