Immune to animals weighing up to 18kg (40lb)
11m x 11m (35ft x 35ft) and up to 15m (50ft) for center beams with 88.5° viewing angle
Extremely high EMI and RFI rejection
PCB uses only surface mount components
Solid-state relay
Patented Auto Pulse Signal Processing
Automatic Temperature Compensation
Metal shield maximizes protection from EMI and RFI signals
Dual element sensor
Anti-tamper switch

Specifi cations:
operates at 11Vdc to 16Vdc;
31mA maximum current consumption;
10V/m rejection from 10MHz to 1GHz;
2.1m to 2.7m(7ft to 9ft) installation height;
0.2m to 3.5m/s (0.6ft to 11.5ft/s) walk speed;
operates at -20°C to +50°C (-4°F to 122°F)
