Outdoor used 2 beams, gain
automatically adjust to meet the rain, fog, snow and other inclement weather.
Special filters and
circuit, anti-glare interference;
Optical lenses to adjust
faster, more convenient and accurate;
Lighting protection
circuit design.
|
Model NO.
|
ABT-20
|
ABT-30
|
ABT-40
|
ABT-60
|
ABT-80
|
ABT-100
|
ABT-150
|
|
Detecting distance(outdoor)
|
20m
|
30m
|
40m
|
60m
|
80m
|
100m
|
150m
|
|
Detecting distance(indoor)
|
60m
|
90m
|
120m
|
180m
|
240m
|
300m
|
450m
|
|
Maximum distance
|
200m
|
300m
|
450m
|
600m
|
800m
|
1000M
|
1500M
|
|
Consumption current
|
35mA max
|
65mA max
|
40mA max
|
65mA max
|
70mA max
|
70mA max
|
75mA max
|
|
Infrared beams
|
two-beams
|
|
Response speed
|
50-700m/sec
|
|
Alarm output
|
1C contact output:contact capacity DC30V/0.5A MAX
|
|
Power, voltage
|
DC13.8V-24V AC11V-18V
|
|
Operating temperature scope
|
-25℃ ~ +55℃
|
|
Tamper output
|
1Bcontact output DC30V/0.5A MAX
|
|
Adjustable angle of optical
axis (horizontal)
|
180°（±90°）
|
|
Adjustable angle of optical
axis (vertical)
|
20°（±10°）
|
|
Weight
|
300g for each transmitter or receiver
|
