Precise detection of plate, tampered and laminated glass breakage
Full audio and infrasonic spectrum analysis
7 frequency digital filters, digital amplifier gain and frequency fluctuation assessment
Impact and shock wave analysis
High‐Immunity to RFI and EMI signals
Sensitivity: High 9m(30ft) or Low 4.5m (15ft)
Testtrek (459) for testing available separately
Operates at 9 to 16 VDC.
17mA max current consumption.
10 V/m rejection from 10 MHZ to 1 GHz.
Anti‐tamper switch(150mA/ 28 VDC, N.C)
Alarm output (form A relay 100mA/28 VDC,N.C)
Operates at -10°C to 50°C (14°F to 122°F)
Alarn Indicator: Red LED on and keep 3 seconds
Alarm Output: NC, 28VDC, 0.15A
Tamper Switch: NC
Working Humidity: 95%
