Ceiling or wall mounting
Tamper lid
Automatic temperature compensation
LED ON & OFF selectable
Adjustable alarm delay
Adjustable detection range
The use of SMD technology anti-EMI RFI interference.

Technical parameters:
Operating voltage: DC9-16V
Quiescent current: 20mA (DC 12V pm)
Ambient temperature: -10 ~ +50
Installation: Wall or Ceiling
Mounting height: 2m left
Detection angle: 15
Detection distance: 6m
Detection range: 6 * 0.7m (3.6m in height when installed)
Alarm Output: NC
Tamper Switch: NC
Size: 86.5 * 48.5 * 32mm
